- SS全不鏽點膠針頭
- 不鏽鋼金屬針頭
| 規格 | 內徑(mm) | 外徑(mm) | 針長1/4"(6.5mm) | 針長1/2"(13mm) | 針長1"(25mm) | 針長1.5"(38mm) |
|---|---|---|---|---|---|---|
| 8G | 3.50 | 4.00 | SS08025 | SS08050 | SS08100 | SS08150 |
| 10G | 2.85 | 3.45 | SS10025 | SS10050 | SS10100 | SS10150 |
| 11G | 2.45 | 2.95 | SS11025 | SS11050 | SS11100 | SS11150 |
| 12G | 2.30 | 2.80 | SS12025 | SS12050 | SS12100 | SS12150 |
| 13G | 1.90 | 2.40 | SS13025 | SS13050 | SS13100 | SS13150 |
| 14G | 1.55 | 2.08 | SS14025 | SS14050 | SS14100 | SS14150 |
| 15G | 1.30 | 1.78 | SS15025 | SS15050 | SS15100 | SS15150 |
| 16G | 1.15 | 1.60 | SS16025 | SS16050 | SS16100 | SS16150 |
| 17G | 1.05 | 1.50 | SS17025 | SS17050 | SS17100 | SS17150 |
| 18G | 0.86 | 1.26 | SS18025 | SS18050 | SS18100 | SS18150 |
| 19G | 0.72 | 1.02 | SS19025 | SS19050 | SS19100 | SS19150 |
| 20G | 0.60 | 0.90 | SS20025 | SS20050 | SS20100 | SS20150 |
| 21G | 0.50 | 0.80 | SS21025 | SS21050 | SS21100 | SS21150 |
| 22G | 0.40 | 0.70 | SS22025 | SS22050 | SS22100 | SS22150 |
| 23G | 0.30 | 0.60 | SS23025 | SS23050 | SS23100 | SS23150 |
| 24G | 0.27 | 0.55 | SS24025 | SS24050 | SS24100 | SS24150 |
| 25G | 0.25 | 0.50 | SS25025 | SS25050 | SS25100 | SS25150 |
| 26G | 0.22 | 0.45 | SS26025 | SS26050 | SS26100 | SS26150 |
| 27G | 0.20 | 0.40 | SS27025 | SS27050 | SS27100 | SS27150 |
| 28G | 0.17 | 0.32 | SS28025 | SS28050 | SS28100 | SS28150 |
| 30G | 0.15 | 0.30 | SS30025 | SS30050 | SS30100 | SS30150 |
| 32G | 0.10 | 0.24 | SS32025 | SS32050 | SS32100 | SS32150 |
| 34G | 0.06 | 0.23 | SS34025 | SS34050 | SS34100 | SS34150 |
